P80 P80F3 Heavy Duty Lumber Conveyor Chain Sharp Top Roller Chain

Ask Lasest Price
Brand Name :	UCER
Model Number :	P80 P80F3
Certification :	ISO9001
Price :	$2.00 - $50.00/ Meter
Payment Terms :	L/C, T/T, D/P, CAD
Supply Ability :	10000 Meters per Month
Delivery Time :	45 work days

Add to Cart

Product Details
Company Profile

P80 P80F3 Heavy Duty Lumber Conveyor Chain Sharp Top Roller Chain

Short Pitch Conveyor Roller Chain With K2 Attachment Double Side Cranked Link Chain

Quick Details:

Place of Origin:Zhejiang, China

Brand Name:UCER

Model Number:P80 P80F3

Structure:Roller Chain

Function:Conveyor Chain

Standard or Nonstandard:Standard

roller chain name:High Quality tooth chain lumber conveyor chain

conveyor chain type:chain with attchments

OEM service:accept

heat treatment:all the chain parts undergo heat treatment

Color:black & gray

tooth chain pitch:76 mm

pin diameter:29.24 mm

roller diameter:48.26 mm

production maker:China manufacturer

size&capacity:pls reference to the form

Supply Ability:10000 Meter/Meters per Month

Specification

Chain NO.	P	H	h	h2 max	G
Chain NO.	mm
50F21	15.875	40	20	13	48

Chain NO.	P	L	h	H
Chain NO.	mm
16B-1180	25.4	46	12.2	22.5

Chain NO.	P	L	h	H	α
Chain NO.	mm
25HF5-6STC	6.35	5.8	8.8	12.2	90°
16B-1185	25.4	46	16	26.5	75°
16B-6STC	25.4	46	16	26.5	73.4°

Chain NO.	P	L	h	H	α
Chain NO.	mm
16B-2STCF1	25.4	15	24.75	24.75	88°
20A-2STCF1	31.75	23	35.95	35.95	80°
20A-2STCF3	31.75	23	35.95	35.95	82°

Chain NO.	P	h	H
Chain NO.	mm
24B-1810	38.1	19	35.5
120F6	38.1	21	38.5

Chain NO.	P	L	h
Chain NO.	mm
16BF6	25.4	46	30
16BF5	25.4	48.8	22.9

Chain NO.	P	h	H
Chain NO.	mm
P80	80	30	58

Chain NO.	Pitch	Roller diameter	Width between inner plates	Pin diameter	Pin length		Plate thickness	Ultimte tensile strength	Average tensile strength	Weight permeter
	P	d1 max	b1 min	d2 max	L max	Lc max	T max	Qmin	Q0	q
	mm							kN/bf	KN	kg/m
P80	80	42	24	15	55	60	6	250/56818	275	11.3

Chain NO.	Pitch	Roller diameter	Width between inner plates	Pin diameter	Pin length		Plate thickness	Ultimte tensile strength	Average tensile strength	Weight permeter
	P	d1 max	b1 min	d2 max	L max	Lc max	T max	Qmin	Q0	q
	mm							kN/bf	KN	kg/m
P80F3	80	30	32	15	58.6	62.6	5	98/20909	107	9.12
P80F32	80	30	30	15	63	72	6	112/25194	123.2	7.28

Packing Delivery Shipping

Packaging Details:Packing: a tooth chain + a poly bag + individual box + a wooden case

Port: shanghai ,ningbo

Delivery Details:

Usually, we pack conveyer chain in polybag and box. then put the box in the creat. we offer yellow or white box for free, which marked length and size only, customer also may offer his box sample to us. our crate dimension: 100×75×75cm(800Kg could be packed)or 105×95×75cm(1000Kg could be packed); Usually 20' container could pack about 20-25 ton, but it depend on the requirement of the customs of every country. Packed chain on the pallet directly also optional.

Recommend Products

Our Service

1. UCER chain supply OEM/ODM service.

2. We have been producing all kinds of standard chains and special chain: Driving Chain, Agriculture Chain, Conveyor Chain, Long Pitch Conveyor Chain, Stainless Steel Chain, Hoisting Chain, Motorcycle Chain, Dropped Forged Rivetless Chain and so on.
