B Series Short Pitch Carbon Steel Roller Chain 04B 05B 06B

Ask Lasest Price
Brand Name :	UCER
Model Number :	A series B series
Certification :	ISO9001
Price :	$3.6.00 - $99.00/ Meter
Payment Terms :	L/C, T/T, , D/P, CAD
Supply Ability :	10000 Meters per Month
Delivery Time :	45 work days

Add to Cart

Product Details
Company Profile

B Series Short Pitch Carbon Steel Roller Chain 04B 05B 06B

A B Series Short Pitch Carbon Steel Stainless Steel Roller Chain Transmission Drive Chains

Quick Detail

Applicable Industries: Garment Shops, Manufacturing Plant, Machinery Repair Shops, Restaurant, Food Shop, Energy & Mining

Standard or Nonstandard: Standard

Type: Roller Chain

Material: ALLOY, Alloy, Carbon Steel

Tensile Strength: 20%more

Place of Origin: Zhejiang, China

Brand Name: Gelin or OEM

Function: Trasmission chain Roller Chain, Driving roller chain

treatment: heart treatment

series: simplex,duplex,triplex

Test &Inspection: BV, SGS,API, and Etc

OEM service: Accept

Colors: Nature, Blue, Yellow

Supply Ability: 10000 Meter/Meters per Month

Specifications :

DIN ISO Chain No.	Pitch		d1 max mm	b1 min mm	d2 max mm	t/T	h2 max mm	Pt mm	L max mm	Lc max mm	U.T.S KN	A.T.S KN	q ≈ kg/m
	mm	inch
04B	6		4	2.8	1.85	0.6	5	-	7.4	10.3	3	3.6	0.12
05B-1	8		5	3	2.31	0.8	7.1	-	7.95	11.7	5	6	0.19
05B-2	8		5	3	2.31	0.8	7.1	5.64	13.6	14.9	6.5	7.8	0.33
06B-1	9.25	3/8"	6.35	5.72	3.28	1.3	8.26	-	13.15	13.5	9	10.8	0.38
06B-2								10.24	23.4	23.8	16.9	20.28	0.74
06B-3								10.24	33.6	34	24.9	29.88	1.1
08B-1	12.7	1/2"	8.51	7.75	4.45	1.6	11.8	-	16.85	18.2	18	21.6	0.74
08B-2								13.92	30.7	32.2	31.1	37.32	1.47
08B-3								13.92	44.6	46	46.65	55.98	2.2
10B-1	15.875	5/8"	10.16	9.65	5.08	1.7	14.6	-	19.5	20.5	22.4	26.88	0.95
10B-2								16.59	36	37.2	44.5	53.4	1.88
10B-3								16.59	52.6	53.8	66.7	80.04	2.81
12B-1	19.05	3/4"	12.07	11.68	5.72	1.85	16.1	-	22.45	23.4	29	34.8	1.23
12B-2								19.46	42.1	42.9	57.8	69.39	2.42
12B-3								19.46	61.6	62.3	86.7	104.04	3.61
16B-1	25.4	1"	15.88	17.02	8.28	3.24	21	-	35.5	36.7	60	72	2.77
16B-2								31.88	68.5	68.6	106	127.2	5.51
16B-3								31.88	99.5	100.5	160	192	8.25
16B-4								31.88	131	132.4	212	254.4	11
20B-1	31.75	1"1/4	19.05	19.56	10.19	4.5	26.4	-	14.4	44	95	114	3.9
20B-2								36.45	77.5	80.6	170	204	7.7
20B-3								36.45	114	116.9	250	300	11.44
20B-4								36.45	149.8	-	325	390	15.18
24B-1	38.1	1"1/2	25.4	25.4	14.63	6	33.4	-	53.5	57.7	160	192	7.14
24B-2								48.36	101.8	106.1	280	336	14.1
24B-3								48.36	150.2	154.4	425	510	20.79
28B-1	44.45	1"3/4	27.94	30.99	15.9	7.6	37	-	65.1	69	200	240	9.36
28B-2								59.56	123.15	128.6	360	432	18.52
28B-3								59.56	183.7	188.2	530	636	27.7
32B-1	50.8	2"	29.21	30.99	17.81	7.1	42.2	-	64.5	70	250	300	9.94
32B-2								58.55	124.1	128.5	450	540	19.6
32B-3								58.55	181.8	187.1	3670	804	29.26
40B-1	63.5	2"1/2	39.37	38.1	22.89	8.6	52.9	-	80	84.3	355	426	16.4
40B-2								72.29	151.6	156.6	630	756	32
40B-3								72.29	224.6	228.9	950	1140	48.3
48B-1	76.2	3"	48.26	45.72	29.24	10	63.88	-	99	105	560	672	25.2
48B-2								91.21	191.2	196.2	1000	1200	50
48B-3								91.21	276.1	284.4	1500	1800	74.8
56B-1	88.9	3"1/2	53.98	53.34	34.32	12.4	77.5	-	116.5	122	850	1020	35
56B-2								106.6	223.1	228.6	1600	1920	69.36
56B-3								106.6	329.7	335.2	2240	2688	103.6
64B-1	101.6	4"	63.5	60.96	39.4	13.5	90	-	131.3	137.3	1120	1344	59.5
64B-2								119.89	251.2	257.2	2000	2400	118.5
64B-3								119.89	371.1	377.1	3000	3600	177.5
72B-1	114.3	4"1/2	72.39	68.58	44.48	16	103.5	-	148.2	154.2	14000	16800	80
72B-2								136.27	284.5	290.5	2500	3000	159
72B-3								136.27	420.7	426.7	3750	4500	238

Straight Side Plate Chain(A series)

ANSI Chain No.	ISO GB/T 1243	Pitch		d1 max mm	b1 min mm	d2 max mm	t/T	h2 max mm	Pt mm	L max mm	Lc max mm	U.T.S KN	A.T.S KN	q ≈ kg/m
		mm	inch
C35-1	06C	9.525	3/8"	5.08	4.77	3.58	1.3	8.7	10.13	12.3	13.3	7.8	9.36	0.35
C35-2										22.4	23.4	15.6	18.72	0.69
C35-3										32.5	33.5	23.4	28.08	1.02
C40-1	08A	12.7	1/2"	7.92	7.85	3.97	1.5	12	14.38	16.4	17.9	13.8	16.56	0.66
C40-2										30.8	32.3	27.6	33.12	1.3
C40-3										45	46.7	41.4	49.68	1.96
C50-1	10A	15.875	5/8"	10.16	9.4	5.05	2.03	15.05	18.11	20.5	21.9	21.8	26.16	1.1
C50-2										38.2	40	43.6	52.32	2.14
C50-3										56.5	58.1	65.4	78.48	3.2
C60-1	12A	19.05	3/4"	11.91	12.57	5.94	2.42	18	22.78	25.48	26.7	31.1	37.32	1.53
C60-2										48.4	49.5	62.3	74.76	3
C60-3										71.3	73.1	93.4	112.08	4.5
C80-1	16A	25.4	1"	15.88	15.75	7.94	3.23	23.5	29.29	32.7	34.1	55.6	66.72	2.63
C80-2										61.8	63.2	111.2	133.44	5.24
C80-3										91.2	94.2	166.8	200.16	7.03
C100-1	20A	31.75	1"1/4	19.05	18.9	9.53	4.8	30	35.76	40	43.1	86.7	104.04	4.03
C100-2										75	78.9	173.5	208.2	8.02
C100-3										110	115.3	260.2	312.24	12
C120-1	24A	38.1	1"1/2	22.23	25.22	11.1	4.8	36.2	45.44	50.5	54	124.6	149.52	5.94
C120-2										95.94	99.4	249.1	298.92	11.84
C120-3										141.4	144.9	391.7	448.44	17.69
C140-1	28A	44.45	1"3/4	25.4	25.22	12.7	5.6	42	48.87	53.5	57.8	169	202.8	7.5
C140-2										102.5	106.7	338.1	405.72	14.89
C140-3										151.5	155.8	507.1	608.52	22.28
C160-1	32A	50.8	2"	28.58	31.55	14.27	6.5	48.26	58.55	64.67	70.67	222.4	266.88	10.2
C160-2										124.02	130.02	444.8	533.76	20.25
C160-3										182.57	188.57	667.2	800.64	30.31

Packing Delivery Shipping

Packaging details : plastic bag+carton box+plywood case for ANSI 50 short pitch precision machine made roller chain oem manufacturer

Port: shanghai ,ningbo
Pin Bush Roller Plate Engineer Design Chain Parts Machine Parts 4

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
