OEM Free Flow Conveyor Roller Chain 12.7 - 25.4 mm

Ask Lasest Price
Brand Name :	UCER
Price :	$3.00 - $50.00/ Meter
Payment Terms :	L/C, , T/T, Western Union
Supply Ability :	10000 Meters per Month
Delivery Time :	45 work days
Model Number :	C2040 C2042 C2060 C2080
Certification :	ISO9001

Add to Cart

Product Details
Company Profile

OEM Free Flow Conveyor Roller Chain 12.7 - 25.4 mm

Side Roller Top Roller Conveyor Chain Free Flow Conveyorr Bucket Elevator Conveyor Chain

Quick Details:

Place of Origin: Zhejiang, China

Brand Name: UCER

Model Number: C2060 C2080

Structure: Roller Chain

Function: Conveyor Chain

Standard or Nonstandard: Standard

Roller chain name: Outboard Roller Conveyor Chain

Conveyor chain type: Side rollers conveyor chain

OEM service: Accept

Heat treatment: All the chain parts undergo heat treatment

Color: black & gray

Pitch: 12.7 - 25.4 mm

Business Type:

Width between inner plates: 7.85 - 15.75 mm

Material: alloy steel or stainless steel

Size&capacity: pls reference to the form


OEM Free Flow Conveyor Roller Chain 12.7 - 25.4 mm

DIN ISO Chain No.		Pich		R max	W min	D max	T max	H max	L1 max	L2 max	L3 max	Ds	Hs	Kg/m
A	B	mm	inch	mm
40	40	12.7	1/2"	7.92	7.85	3.98	1.5	12.07	9.95	18	19.5	15.88	7.8	1.85
50	50	15.875	5/8"	10.16	9.4	5.09	2.03	15.09	12	21.8	23.5	19.05	9.4	2.64
60	60	19.05	3/4"	1.91	12.57	5.96	2.42	18.08	14.75	28	30.6	22.23	12.6	3.85
80	80	25.4	1"	15.88	15.75	7.94	3.25	24.13	19.25	35.2	38.2	28.58	15.8	6.16
100	100	31.75	1"1/4	19.05	18.9	9.54	4	30.18	22.85	43	45.9	39.69	19	10.22

DIN ISO Chain No.		Pich		R max	W min	D max	T max	H max	L1 max	L2 max	L3 max	Ds	Hs	Kg/m
A	B	mm	inch	mm
C2040	C2040	25.4	1"	7.92	7.85	3.98	1.5	12.07	9.95	18	19.5	15.88	7.8	1.08
C2042	C2042			15.88										2.07
C2050	C2050	31.75	1"1/4	10.16	9.4	5.09	2.03	15.09	12	21.8	23.5	19.05	9.4	1.55
C2052	C2052			19.05										2.88
C2060	C2060	38.1	1"1/2	11.91	12.57	5.96	3.25	18.08	17.4	29.85	32.25	22.23	12.6	2.65
C2062	C2062			22.23										3.96
C2080	C2080	50.8	2"	15.88	15.75	7.94	4	24.13	21.3	36.85	39.85	28.58	15.8	4.38
C2082	C2082			28.58										6.55
C2100	C2100	63.5	2"1/2	19.05	18.9	9.54	4.8	30.18	25.55	44.4	47.5	39.69	19	7.08
C2102	C2102			39.67										11.1

Packing Delivery Shipping

Packaging Details:Packing: a side rollers conveyor chain + a poly bag + individual box + wooden case

Port: shanghai ,ningbo

Delivery Details:

Usually, we pack conveyer chain in polybag and box. then put the box in the creat. we offer yellow or white box for free, which marked length and size only, customer also may offer his box sample to us. our crate dimension: 100×75×75cm(800Kg could be packed)or 105×95×75cm(1000Kg could be packed); Usually 20' container could pack about 20-25 ton, but it depend on the requirement of the customs of every country. Packed chain on the pallet directly also optional.

Recommend Products

Our Service

1. UCER chain supply OEM/ODM service.

2. We have been producing all kinds of standard chains and special chain: Driving Chain, Agriculture Chain, Conveyor Chain, Long Pitch Conveyor Chain, Stainless Steel Chain, Hoisting Chain, Motorcycle Chain, Dropped Forged Rivetless Chain and so on.
