High temperature resistant conveyor belt ST1250 Special Conveyor Belts

1. Purpose

It is mainly used in metallurgy, construction and other industries to transport high-temperature materials such as sinter, coke, cement clinker, etc. The material temperature does not exceed 800℃, and the belt surface temperature does not exceed 220℃. Features: Use EPDM rubber as the covering layer, and use domestic special high-temperature resistant canvas as the skeleton material. The unique formula design solves the key problems of high saturation of ethylene propylene rubber, poor adhesion, and low interlayer adhesion. . It has the characteristics of light belt body, long life (about 2-4 times) and good heat resistance.
The implementation of the "Conveyor Belt with Rubber or Plastic Covering Layer of General Purpose Fabric Core Conveyor Belt" standard, this standard adopts the draft international standard ISO/FDIS14890-1999 standard
The heat-resistant conveyor belt is made of multi-layer rubber cotton canvas (poly-cotton cloth) or polyester canvas covered with high-temperature or heat-resistant rubber and bonded together by high-temperature vulcanization. It is suitable for conveying hot coke, cement, and slag below 175°C. And hot castings, etc.
1) The specifications are the same as ordinary conveyor belts.
2) The product implements the HG2297-92 standard.
3) Heat-resistant conveyor belts can be divided into four types:
Type I: It can withstand test temperature not greater than 100℃, the highest short-time operating temperature is 150℃, code T1.
Type Ⅱ: It can withstand the test temperature of not more than 125℃, the maximum short-time operating temperature is 170℃, and the code is T2.
Type Ⅲ: It can withstand the test temperature of not more than 150℃, the highest short-time operating temperature is 200℃, and the code is T3.
Type IV: Can withstand test temperature not greater than 175℃, maximum short-time operating temperature 250℃, code T4.

2. Use matters needing attention

With the popularity of conveyor belts in industrial production, multiple varieties, high performance, light weight, multi-function, and long life are several aspects that manufacturers pay attention to. In industrial production, the correct use of conveyor belts is particularly important. The following items should be paid attention to in the use of conveyor belts:
1) Avoid the roller being covered by the material, causing the rotation failure, prevent the leakage of the material from getting stuck between the roller and the belt, pay attention to the lubrication of the movable part of the conveyor belt, but do not oil the conveyor belt;
2) Prevent the conveyor belt from starting under load;
3) If the conveyor belt deviates, measures should be taken to correct it in time;
4) When the conveyor belt is found to be partially damaged, use artificial cotton to repair it

<

CDINDUSTRY(INTERNATIONAL).INC.(Hereinafter referred to as CDI) is located in Chongqing Yubei District of southwest of China. The main business involves the equipment supply and after-market outsourcing in the area of Metallurgy, Cement and Oil&Gas field. Also CDI established UCER for providing professional conveyor belt&conveyor chain to customers.

UCER is a professional manufacturer of conveyors belts and conveyor chains integrating product development, research, design, manufacturing, sales and service. The company has passed ISO9001:2009 international quality management system certification. After years of hard work, our partners have spread all over the country, and its products are exported to Europe, America, Asia, Africa, and Australia.

The company’s conveyors belt products mainly include steel wire rope core conveyor belts, steel wire rope hoisting belts, bucket elevator conveyor belts, sidewall conveyor belts, large inclination corrugated sidewall conveyor belts, plain cotton conveyor belts, cotton canvas conveyor belts, nylon conveyor belts, polyester (EP ) Conveyor belt, white rubber conveyor belt, steel cable conveyor belt, steel cable belt, pattern conveyor belt, whole core non-flammable conveyor belt, flame retardant conveyor belt, PU conveyor belt, light conveyor belt, PVC conveyor belt and PVG conveyor belt, etc. As for conveyor chain, we have been producing all kinds of standard chains and special chain: Driving Chain, Agriculture Chain, Conveyor Chain, Long Pitch Conveyor Chain, Stainless Steel Chain, Hoisting Chain, Motorcycle Chain, Dropped Forged Rivetless Chain and so on.

For a long time, the company has been committed to the promotion of ports, metallurgy, mining, coal, foundry, building materials, food, chemical and other markets, and has won praise and support from users.
